NPZ25-206
High-precision piezo stage
Compact, flexure-guided nanopositioning actuator made of Super Invar.
| Part Number | 3715206 |
| Footprint | 44mm H x 20mm ∅ |
| Material | Super Invar |
| Maximum Load | 1kg |
| Max Force (Push/Pull) | 100N/20N |
| Stage Mass | 90g |
| Nanomotion Control | Z |
| Closed-loop Travel | 25µm |
| Open-loop Travel (-30 to 150 V) | 40µm |
| Position Noise | 0.1nm |
| Stiffness | 20.0N/µm |
| Resonant Frequency | 4000Hz |
| Settling Time | 2ms |
| Linearity Deviation | 0.01% |
| Capacitance | 1.6µF |
| Integrated Sensor | Capacitive |
| Cable Length | 2m |
| Controller | LC.400 |
Here are the different products or controllers that are related to this product:
Related Resources:
What is a Piezo Flexure Stage?
A Piezo Stage can be characterized as a mechanical device, driven by a piezoelectric actuator, which provides one or more axis of motion.
